- Impact diagnostics thermal camera for diagnositcs RX-500
Product details
Impact diagnostics RX-500 serves as an Infrared Thermal Camera designed for the commercial, electrical, facility, HVAC, and many more maintenance applications, to simplify their repair and maintenance reporting. It is an ideal option for those who need an Infrared Thermal Camera with top-notch thermal imaging and advanced features at a limited budget.
TECHNICAL SPECIFICATIONS
Infrared Image Resolution: 220*160
Display Screen: 3.2”full angle TFT display screen
LCD Resolution: 256*192
Visible Image Solution: 300,000 pixel
Field Angle: 5°×26°
Shortest Focus Length: 0.15m (5.91 inch)
Thermal Sensitivity: 0.07°C (0.126°F)
Temperature Measurement Range: -20℃ to 550℃
Measurement Accuracy: ±2℃/±2%
Emissivity: Adjustable from 0.01to 1.00
Wavelength Coverage: 8-14um
Focus Mode: Fixed
Color Palette: Rainbow, iron oxide red, cold color, black & white, white & black
Storage Capacity: Built-in 3G (above 20 thousand image stored)
Power Supply: Built-in Lithium Battery
Continuous Work Time: 3hours
Automatic Power-off Time: Selectable5 minutes/20 minutes/ not power off automatically
Language: English, Chinese, Italian, German
Head Unit Size: 90*105*223 mm (3.54*4.13*8.78 inches)
Head Unit Weight: 389g (0.86 lb)
Work Temperature: 0°C~45°C (32°F~113°F)
Frame Rate of Thermal Images: 9Hz
same as TOPDON ITC629 thermal camera
